Fluoroplastic Insulated Computer Cable

Product Usage:

Fluoroplastic insulated computer cable uses fluoroplastics (such as polytetrafluoroethylene PTFE or FEP) as the insulation layer, making it a high-performance, highly corrosion-resistant data transmission cable. Fluoroplastic materials have electrical insulation properties, high-temperature resistance, and chemical stability, maintaining performance in extremely harsh environments. This cable also has outstanding aging resistance, radiation resistance, and flame retardancy, suitable for data transmission needs in special environments such as high humidity, strong corrosion, high or low temperatures. It is widely used in aerospace, petrochemicals, medical equipment, and other fields, ensuring the safety and reliability of data transmission.

PREV：Computer Control Cable for Intrinsically Safe CircuitsNEXT：PE Insulated Computer Cable
Parameter

This product is suitable for computer distributed control systems with an AC rated voltage (U₀/U) of 450/750V and below, transmitting analog and digital signals for detection, control, interlocking, and alarming of process variables in production units. In addition to having good resistance to magnetic field interference, electrostatic interference, and other performance characteristics, this product also exhibits excellent resistance to high and low temperatures, chemical corrosion, oil, and is non-flammable.

Fluoroplastic insulated high-temperature measurement and control cable for computer systems complies with Q/321084KLB09-2009.

Type

Names of products

JFPF-1

Copper core structured, fluoroplastic insulated, copper wire braiding sub-shield, screened fluoroplastic sheathed high-temperature detection and control computer cable.

JFPF-2

Copper core structured, fluoroplastic insulated, copper wire braiding sub-shield and overall-shield screened. fluoroplastic sheathed high-temperature detection and control computer cable.

JFPF-3

Copper core structured, fluoroplastic insulated, copper wire braiding overall-shield screened, fluoroplastic sheathed high-temperature detection and control computer cable.

JFPF-1

Copper core structured, fluoroplastic insulated, copper strip sub-shield screened, fluoroplastic sheathed high-temperature detection and control computer cable.

JFPF-2

Copper core structured, fluoroplastic insulated, copper strip sub-shield and overall-shield screened, fluoroplastic sheathed high-temperature detection and control computer cable.

JFPF-3

Copper core structured, Huoroplastic insulated, copper strip overall-shield screened, fluoroplastic sheathed high-temperature detection and control computer cable.

JFPF2F-1

Copper core structured, fluoroplastic insulated, copper wire braiding sub-shield screened, steel strip armor shielded, fluoroplastic sheathed high-temperature detection and control computer cable.

JFPF2F-2

Copper core structured, fluoroplastic insulated, copper wire braiding sub-shield and overall-shield screened,  steel strip armor shielded, fluoroplastic sheathed high-temperature detection and control computer cable.

JFPF2F-3

Coppe core structured, fluoroplastic insulated, copper wire braiding overall-shield screened, steel strip armor shielded, fluoroplastic sheathed high-temperature detection and control computer cable.

JFP2F24-1

Copper core structured, fluoroplastic insulated, copper strip sub-shield screened, steel strip armor shielded,  fluoroplastic sheathed high-temperature detection and control computer cable.

JFP2F24-2

Copper core structured, fluoroplastic insulated, copper strip stb-shield and overall shield screened, steel strip armor shielded, fluoroplastic sheathed high-temperature detection and control computer cable.

JF2PF24-3

Copper core structured, fluoroplastic insulated, copper strip overall-shield screened, steel strip armor shielded,  fluoroplastic sheathed high temperature detection and control computer cable.

JFPG-1

Copper core structured, fluoroplastic insulated, copper wire braiding sub-shield screened, silastic sheathed high-temperature detection and control computer cable.

JFPG-2

Copper core structured, fluoroplastic insulated, copper wire braiding sub-shield and overall-shield screened, silicone sheathed high-temperature detection and control computer cable.

JFPG-3

Coppe core structured fluoroplastic insulated, copper wire braiding overall-shield screened, silastic sheathed high-temperature detection and control computer cable.
